AutoLED II™

Please note this item was discontinued in January of 2017

Utilising the same core technologies as the innovative Chroma-Q® Studio Force D XT 12™, the new AutoLED II™ is a 6,500K* CCT daylight white LED moving head fixture that boasts an extreme 16,430* lumens output for ultra bright, long distance throw; a high CRI; and a smooth linear dimming curve. Specifically designed for providing precise daylight illumination of motor industry tradeshows, fashion events, and retail environments, the AutoLED II incorporates DMX control, allowing it to be operated from any DMX enabled lighting console – saving time, energy, and manpower when rigging, focusing, and cabling fixtures. AutoLed features an optional beam Shaper in the form of an electronic frost system (E-Frost) to dynamically diffuse the light beam.

Key Features

  • 6,500K* CCT (+/-200K) Daylight White
  • Extreme output – up to 16,430 lumens
  • High CRI
  • Precise daylight illumination
  • Energy-efficient LED light source
  • Extremely smooth, uniform wash
  • Theatrical grade dimming
  • Ideal for tradeshows, fashion & retail events, broadcast & performance applications
  • 16-bit pan & tilt movement
  • Camera friendly
  • Comes supplied with louver accessory
  • Optional beam shaper efrost dynamic diffusion kit accessory available
  • Built-in power supply

Request A Demo



Ultra Bright
Utilising the very latest generation of LED and optics, the AutoLED II offers an ultra bright output of 16,430 lumens.

Multi-purpose
The AutoLED II™ provides precise daylight illumination for a wide range of event lighting applications including key-lighting, uplighting, backlighting, and wash applications.

Accessories
The AutoLED II™ comes supplied with a louver accessory. A revolutionary beam shaper lens plate (E-Frost Dynamic Diffusion) - custom developed by Chroma-Q for remote control of beam angle adjustment - is also available as an optional accessory.

Energy Saving & Low Maintenance
Utilising Chroma-Q's latest LED technologies, the AutoLED II draws an extremely low power consumption of 300* watts, offering a significant return on your investment with its high energy efficiency compared to conventional discharge fixtures. In addition, there are no lamps to degrade and need replacing over time.

16-Bit Pan & Tilt Movement
Incorporating 16-bit pan & tilt movement, the AutoLED II allows you to fine-tune your beam placement via DMX control for extremely accurate positioning - saving you the time and manpower needed to manually focus conventional discharge fixtures.

Colour
The AutoLED II™ includes ColorSure™ technology for enhanced consistency across each light engine when using multiple fixtures.

Optics & Dimming
Featuring a camera friendly custom optical design, the AutoLED II™ provides a smooth, uniform output, matched by theatrical grade dimming.

Practical & Mechanical
On the outside, the AutoLED II™ has been designed to provide maximum versatility and ease of use. The built-in power supply and 5-pin DMX connectors in and out provide fast deployment and simple cable management – as well as allowing for remote focusing and fixture adjustment.

Product Code CHAUDXYII
Net Dimensions
(without fixings)
330mm x 400mm x 216mm / 13" x 15.75" x 8.5"
New Weight 9 kg / 20 lbs
Shipping Dimensions 425mm x 400mm x 295mm / 16.75" x 15.75" x 11.75"
Shipping Weight 11 kg / 24 lbs
Power Supply Built-in
Power Input Rating 100-240V AC 50-60Hz 300VA
Power Factor 0.9
Power Consumption 300W
Typical Power & Current Measurements done with all LEDs at maximum intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Power Connectors In/Out IEC (Input)
Data Connectors In/Out XLR 5-pin
Control Protocol ANSI E1.11 USITT DMX 512-A
Cooling System Forced - 3 fans
Operating Temperature 0°C to 40°C
Construction Powder coated aluminium base with plastic cover & anodised aluminium extrusion head
Colour Black
Built-In Hardware Base handles and removable louver accessory
IP Rating IP20
Approvals CISPR 22:2008/EN55022:2010 (Class A) & CISPR 24:2010/EN55024:2010, ICES-003:2012, FCC Part 15 Subpart B:2012, CSA C22.2 No. 166-M1983 (R2013), UL 1573 (R:2014), IEC 60598-2-17
Pan movement range 540°
Tilt movement range 270°
Movement resolution 16 Bits
Total LEDs 48 Cold White
Control Modes 5 channels for Pan, Pan Fine, Tilt, Tilt Fine & Intensity
Dimming Curve Theatrical
Hot Lumen Output (Combined) 16,430
Optics Specialised close focus lens
Beam Angle ~17°
Beam Distribution Symmetrical direct illumination
CCT 6500K
CRI >=70
Lamp Life L70 at 50,000 hours
