Color Block 2 Plus™ Nano

The Chroma-Q® Color Block 2 Plus™ Nano is an ultra compact, low-profile and versatile single cell version of the Color Block 2 Plus™ fixture, which shares the unit's single colour RGBA optics, high light output and theatrical grade dimming to create an exceptional all-round feature set.

Key Features

  • Compact size and lightweight
  • Minimum CRI of 90 – for tungsten emulation
  • Efficient light output of 100 Lumens
  • Extensive colour range - create subtle theatrical hues
  • Single colour diffused optics - virtually eliminate multicoloured shadows
  • Camera friendly output
  • Exceptional colour brightness & light output levels
  • To be used with the standard Colorblock 2 Plus PSU05 or PSU30 power supplies and the Nano Fan Out Box
  • Fixtures use RJ45 connectors to connect to fan out box

Request A Demo

Discreet, Lightweight Design
Based on the same LED engine technology in the popular Color Block 2 Plus, the Color Block 2™ Nano is a non-obtrusive, lightweight LED fixture, perfect for discreet placements such as set piece, architectural and stage lighting.

Extremely Bright and Efficient Light Output
Providing an output of 100 lumens, the Color Block 2 Plus Nano has a very small footprint, packing an incredibly powerful punch for its size and weight.

Extensive Colour Palette
With its extensive colour palette and high CRI of 90, the Color Block 2 Plus™ Nano is capable of creating a wide spectrum of colours, from vibrant bolds, to subtle theatrical hues. Incorporating advanced built-in variable colour temperature capabilities, the Color Block 2 Plus Nano also includes tungsten emulation mode.

Single Colour Diffused Optics
The unit's camera-friendly LED cell minimises glare and camera flicker - mixing beautifully to provide single colour output, virtually eliminating the frustrating colour separation shadows synonymous with LED lighting.

Power and Distribution
Up to 20 Nano units can be used with one standard PSU05B power supply (when used with 5 x Fan Out Boxes) and up to 120 Nano units can be used with one standard PSU30 power supply (when used with 30 x Fan Out Boxes). Color Block 2 Plus Nano and Color Block 2 Plus units can be powered from a single power supply up to the PSU's maximum capacity – i.e. eight Nano units (used with 2 x Fan Out Boxes) and three Color Block 2 Plus units can be run from a single PSU05B.

Theatrical Grade Dimming
In addition, the unit provides a smooth, theatrical grade dimming experience, whilst retaining the instant strobe-like control of intensity normally associated with LED technology.

Product Code CHCBN
Net Dimensions 87mm x 126mm x 62 / 3.4" x 5" x 2.5"
Net Weight 0.3 kgs. / 0.7 lbs.
Shipping Dimensions 305mm x 127mm x 171mm / 12.5" x 5" x 6.75" (Box of 4 units)
Shipping Weight 1.8 kg / 4 lbs (Box of 4 units)
Power & Connections Daisy-chained power & data connections via external 4-way splitter
Power Supply External - PSU05B & PSU30
Power Input Rating 48V DC per 4-way external splitter box
Power Factor See power supply specification sheets
Power Consumption See power supply specification sheets
Power Connector In/Out RJ45 Chassis
Data Connectors In/Out RJ45 Chassis
Max Cable Run 3m / 10' (from external 4-way splitter to fixture)
Control Protocol ANSI E1.11 USITT DMX 512-A
Cooling System Convection
Operating Temperature 0°C to 40°C
Construction Anodised aluminium extrusion
Colour Black
Built-In Hardware 2 x M10 nuts
IP Rating IP20
Approvals CE
LED Engines 1
LEDs Per Engine 12 (3 x RGBA)
Total LEDs 12
Control Modes PSU05B: 67 channels FxHSI, 60 channels HSI, 60 channels RGB (*Magic Amber), 21 channels FxHSI, 15 channels HSI, 15 channels RGB (*Magic Amber), 9 channels FxHSI, 3 channels HIS, 3 channels RGB (*Magic Amber), 80 channels RGBA, 80 channels RGBI, 20 channels RGBA, 20 channels RGBI (*Magic Amber), 4 channels RGBA, 4 channels RGBI (*Magic Amber), 1 channel Look Select; PSU30: 367 channels FxHSI, 360 channels HSI, 360 channels RGB (*Magic Amber), 96 channels FxHSI, 90 channels HSI, 90 channels RGB (*Magic Amber), 9 channels FxHSI, 3 channels HSI, 3 channels RGB (*Magic Amber), 480 channels RGBA, 480 channels RGBI (*Magic Amber), 120 channels RGBA, 120 channels RGBI (*Magic Amber), 4 channels RGBA, 4 channels RGBI (*Magic Amber), 1 channel Look Select
Dimming Curve Theatrical
Variable Effects Engine Yes
Effects Parameters Grouping, colour speed, fan, range, step, intensity effects, intensity fan
Hot Lumen Output (Combined) 100
Optics Specialised close focus lens
Beam Angle 25° (approx.)
Beam Distribution Asymmetrical direct illumination
CCT Adjustable 1,000 - 10,000K
Colour gamut Performance enhanced
CRI 90
Lamp Life L70 at 50,000 hours
