Color Force 12™

Please note this item was discontinued in April of 2019

The Chroma-Q® Color Force 12™ is a truly multi-purpose LED fixture that is suitable for numerous entertainment lighting disciplines. The unit provides power across the spectrum, from deep cold blues to red hot lava looks all from a single fixture. At only 335mm / 1ft* long, the unit is ideal for floor, wall or truss mounting. It also provides a massive output of 2,400 lumens, easily washing up to 8m / 26ft with smooth, theatrical grade dimming.

*Measurements may have been rounded, please see specification sheet for full measurements.

Key Features

  • Huge RGBA full colour palette and high CRI of 92
  • Deep cold blues and red hot lava looks from a single fixture
  • Extremely smooth uniform wash
  • Massive output across the spectrum - 2,400 lumens
  • 335mm / 1ft* length ideal for floor, wall or truss mounting
  • Suitable for numerous entertainment lighting disciplines

Request A Demo

Multi-purpose
The Color Force 12™ is suitable for numerous entertainment lighting disciplines, including uplighting, pipe-end, shin-busting, backlighting and wash applications.

Mighty Output
Producing 2,400 lumens output, the CF12 can also be used to extend Color Force 48 and 72 LED batten installations.

The mighty power output ensures seamless wall washing up to 8m / 26ft.

Opposite demonstrates the Color Force output compared to a traditional 1kW cyc flood. Identical camera setting were used in the comparative photos.

Power across the Spectrum
The Color Force 12™ uses its huge RGBA colour mixing palette to deliver a full range of high brightness colours across the spectrum.

Deep cold blues and red hot lava looks are all available from a single Color Force fixture.

Colour
The Chroma-Q® RGBA engine has been developed to deliver an incredible CRI of 92, for true colour balance across the spectrum.

Optics
The Color Force custom optical design provides a smooth, uniform output with outstanding colour blend across the spectrum.

Separate discreet RGBA LEDs are used for increased efficiencies and the custom Chroma-Q optical design delivers surprisingly clean shadows for most common real world applications.

Theatrical grade dimming, a high CRI of 92 for extremely accurate colour rendition and a clean white ensures the light output feels just right.

Cost Effective
In everyday use the Color Force 12™ is roughly comparable in output and cost to a 750W PAR with colour changer and dimmer channel.

Energy Efficient
With a 50,000 hour L70 lamp life and over 80% power saving when compared to a 750W PAR (even more at saturate colours), the ongoing financial savings of the Color Force 12™ are huge. It is anticipated the unit will actually pay for itself within 13,500 hours of use*.

*Savings
13,500 hr x 630W = 8505 kWh.
8505 kWh x 12.5p** = £1,063
**Typical UK kWh price August 2010

Control
Compatibility with industry standard control consoles is assured.

HSI, RGB, RGBA, RGBI and StRGBA DMX modes are all included.

Practical & Mechanical

  • Stand-alone Master and Slave modes ensure synchronisation of dynamic looks and create additional usage possibilities

  • Mains power and DMX in out for simple cable management

  • Hidden quick release fixings for fast deployment

  • Minimal distance between fixtures for seamless wall washing

  • Built-in power supplies

  • Rugged yet lightweight extruded aluminum body

Product code CHCF12NFRGBA
Dimensions 335mm x 190mm x 218mm / 13.2" x 7.5" x 8.6"
Weight 4kgs / 9lbs
Power Supply Built-in
Power Input Rating 100-240V AC, 50-60 Hz, 160VA
Power Factor 0.997
Power Consumption 120W
Typical Power & Current Measurements done with all LEDs at max. intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Power Connectors In/Out PowerCon
Data Connectors In/Out XLR 5-pin
Max cable run NA
Control Protocol ANSI E1.11 USITT DMX 512-A
Cooling Forced - 1 fan
Operating Temperature 0°C to 40°C
Construction Anodised aluminium extrusion
Colour Black
Built-in Hardware Quick release lever for tilt adjustment
IP rating IP20
Approvals CISPR 22 :2006/EN55022 :2006 & CISPR 24 :1997/EN55024 :1998, ICES-003 :2004 & FCC Part 15 Subpart B: 2007, CSA C22. No. 166-M1983:R2008 UL 1573:2003; UL 8750
LED Engines 2
LEDs Per Engine 24 (6 x RGBA)
Total LEDs 48
Control Modes 7 channels Fx HSI
6 channels HSI Duo
6 channels RGB (Magic Amber**) Duo
8 channels RGBA Duo
9 channels St RGBI (Magic Amber**) Duo
5 channels St RGBA
3 channels HSI
3 channels RGB (Magic Amber**)
4 channels RGBA 4 channels RGBI (Magic Amber**)
1 channel DMX Look Select
Master Standalone
Slave Standalone
Dimming Curve Theatrical
Variable effects engine Yes
Effects Parameters Colour speed, colour range, colour step, and intensity effects
Hot Lumen Output (Combined) White 2,400 lumen
Optics Specialised close focus lens
Beam angle 23° (approx.)
Beam angle with optional Cyc optic 80° x 30° (approx.)
Beam angle with optional Border optic 60° (approx.)
Beam distribution Asymmetrical direct illumination
CCT Adjustable 1,000-10,000K
Colour Gamut Performance enhanced
CRI 92
Lamp life L70 up to 50,000 hours
