Color Force Compact™

Please note this item was discontinued in August of 2019

The Chroma-Q® Color Force Compact™ is a powerful creative lighting tool that works in perfect harmony with the popular Color Force™ range. The Compact is a cost-effective workhorse, ideal for a wide range of applications. Utilising core LED technology from the Color Force™ range, the fixture provides 1700 lumens in a cost-effective, slim, compact profile, while maintaining colour compatibility with the rest of the range.

Key Features

  • Compact yet powerful - 1700 lumens from a very small footprint
  • IP65 rated
  • Multi-purpose-workhorse fixture - suitable for a wide range of applications
  • Deep cold blues, red hot lava and super-soft pastels - from a single fixture
  • High CRI of 92 - true colour balance across the spectrum
  • Custom optics - ensure a smooth even beam
  • Theatrical grade dimming - suitable for a wide range of applications
  • Accepts City Theatrical accessories - use with your existing accessories

Request A Demo

Please note this item was discontinued in August 2019

Compact Yet Powerful
Despite measuring only 235mm / 9.25" in length, the Color Force Compact™ produces a powerful 1700 lumens output - making it ideal for lighting areas with a very small footprint.

Multi-Purpose Workhorse Fixture
With its rugged external design and IP65 rated casing, the Color Force Compact™ has been designed as a multi-purpose workhorse fixture suitable for numerous entertainment lighting applications - including uplighting, pipe-end shin-busting, backlighting, truss toner and other wash applications.

Fast & Efficient Set-Up
Up to five fixtures can be daisy-chained from each 15-way Compact PSU output, eliminating the need to home-run a cable from each fixture back to the PSU. In addition, up to four fixtures per output can be daisy-chained on a Chroma-Q Color Block PSU (PSU-05B, PSU530).

Cost-Effective Investment
The Color Force Compact™ enables an even wider range of users and budgets to utilise the power of the Color Force as a creative lighting tool.

Power Across The Spectrum
The Color Force Compact™ uses its huge RGBA colour mixing palette to deliver a full range of high brightness colours across the spectrum. Deep cold blues, red hot lava looks and super soft pastels are all available from a single fixture.

Colour
The Chroma-Q® RGBA engine has been developed to deliver an incredible CRI of 92, for true colour balance across the spectrum.

Optics & Dimming
The Color Force Compact™ fixture's custom optical design provides a smooth, uniform output with outstanding colour blend across the spectrum.

Separate discreet RGBA LEDs are used for increased efficiencies and the custom Chroma-Q optical design delivers surprisingly clean shadows for most common real world applications.

Theatrical grade dimming, a high CRI of 92 for extremely accurate colour rendition and a clean white ensures the light output feels just right.

Full Range Of Accessories
For real versatility and compatibility with existing lighting inventories, the Color Force Compact is compatible with City Theatrical top hat, half top hat, egg crate louver and barn door accessories.

The fixture is supplied with a holder for these four optional accessories, as well as interchangeable clear and frosted glass light lenses.

An optional W-DMX wireless accessory for the 15-way PSU is also available.

Full Range Of Creative Tools
Complementing other models in the range, the Color Force line up now provides a full choice of creative tools for almost any entertainment application.

Control
Compatibility with industry standard control consoles is assured. HSI, FxHSI, RGB (*Magic Amber), RGBA, RGBI (Magic Amber), Look Select, Master and Slave Standalone control modes.

*Magic Amber is the term used for the unit's ability to bring in amber when mixing colours that require it.

Product code CHCFCRGBA
Dimensions 212mm x 196mm x 152mm / 8.4" x 7.7" x 6"
Weight 4 kgs / 8.5 lbs
Shipping Dimensions 267mm x 254mm x 241mm / 10.5" x 10" x 9.5"
Shipping Weight 5.4kgs / 12 lbs
Power & Connections Daisy-chained power & data connections
Power Supply External - PSU15 | External - PSU5
Power Input Rating 48V DC
Power Consumption 60 watts
Typical Power & Current Measurements done with all LEDs at max. intensity. Measurements made at nominal voltage. Allow for deviation of +/- 10%
Power Connector In/Out XLR 4-pin
Data Connector In/Out XLR 4-pin
Max Cable Run ~60m / 200ft (PSU to last unit)
Control Protocol ANSI E1.11 USITT DMX 512-A
Cooling System Convection
Operating Temperature 0°C to 40°C
Construction Cast machined enclosure
Colour Black
Built-In Hardware Yoke Assembly
IP Rating *IP65
Approvals CISPR22 :2006/EN55022 :2006 & CISPR 24:1997/ EN55024 :1998, ICES-003 :2004 & FCC Part 15 Subpart B: 2007
LED Engines 1
LEDs Per Engine 28 (7 x RGBA)
Total LEDs 28
Control Modes 52 channels FxHSI, 45 channels HSI, 45 channels RGB, 15 channels FxHSI,
9 channels HSI, 9 channels RGB, 9 channels FxHSI, 3 channels HSI, 3 channels RGB, 60 channels RGBA, 61 channels sRGBI, 12 channels RGBA, 13 channels sRGBI, 4 channels RGBA, 5 channels sRGBI, Look Select, Master Standalone, Slave Standalone
Dimming Curve Theatrical
Variable Effects Engine Yes
Effects Parameters Grouping, colour speed, colour fan, colour range, colour step, intensity effects, intensity fan
Hot Lumen Output 1700
Red 350
Green 960
Blue 90
Amber 700
Optics Specialised close focus lens
Beam Angle 14° (approx.)
With Optional Frosted Optic 21° (approx.)
Beam Distribution Asymmetrical direct illumination
CCT Adjustable 1,000 - 10,000K
Colour Gamut Performance enhanced
CRI 92
Lamp Life L70 at 50,000 hours
